Pinnacle Master
Pinnacle Master

IN3078SL - Master - -

Pinnacle Master

Features

DCI-P3 wide colour space

Designed to deliver richer, more lifelike colours, especially in digital cinema and HDR displays. Compared to sRGB, DCI-P3 covers about 25% more of the visible colour spectrum, enhancing reds, greens, and overall vibrancy to create a more immersive visual experience.

Full user control for your home environment

User adjustment settings allow for image brightness, contrast, saturation, greyscale and sharpness coupled with the unique LED backlight adjustment control.

Master your equalizer settings for the perfect sound

User setting mode to adjust equalizer settings in the 1.5Ghz, 5Ghz, 10Ghz, 120Ghz, 500Ghz channels.

Controller – Remote, Gesture & Trackpad

Download the mobile app for your Pinnacle projector from Apple App Store and Google Play and take control. Other features of the app included embedded users guides and customer service contact page.

Playback settings for your video, audio and image files

Set how files are handled when being played back from a USB drive or directly from the projector’s 32GB of storage.

Display

Display Technology
LCD
Native Resolution
1920 × 1080
Aspect Ratio
16:9
Light Source
LED
Brightness (ISO Lumens)
600
Lamp Life (hours)
25,000
Contrast Ratio
2500:1
Projection Mode
Front Desk Top, Front Tripod, Ceiling Front, Rear Desk Top, Rear Tripod, Ceiling Rear
Minimum Image Size (inches)
50"
Maximum Image Size (inches)
150"

Optical

Throw Ratio
1.27:1
Digital Zoom
50% – 100%

Connectivity

Wi-Fi
2.4GHz / 5.0GHz Wi-Fi 6
Bluetooth
5.2
Connectivity
HDMI 2.1 (eARC), USB-A, AUX

Power

Power Input
TBA
Power Consumption (W)
65
Standby Power
<0.5
Battery
Battery

Audio

Speaker (W)
1 × 5
Audio Modes
Standard, News, Music, Movie, User

Embedded System

CPU
MTK9629
RAM (GB)
2
ROM (GB)
32
OS
Google TV 12
Modes
Projection, Speaker
OTA
Supported
App Store
Google Play Store
Display Modes
Standard, Vivid, Soft, User

General

Product Weight (kg)
3.3
Shipping Weight (kg)
TBA
Product Dimensions (mm)
316 × 306 × 263
Shipping Dimensions (mm)
TBA
Noise (dB)
<32
